7000 HQ1 AC/C P4 Ceramic Ball Bearings (10x26x8mm) Machine Tool Bearing TMP type High Speed Spindle bearings

Контакт

Подробное описание продукта

Высокий свет:	7000 Ceramic Ball Bearing , 10x26x8mm bearing , 7000 HQ1 bearing

Высокий свет:

7000 Ceramic Ball Bearing

7000 HQ1 AC/C P4 Ceramic Ball Bearings (10x26x8mm) Machine Tool Bearing TMP type High Speed Spindle bearings
A . Ceramic Ball Bearings Parameters
Brand-	TMP
Structure-	Ceramic Ball/Angular Contact ball
Model number-	7000 HQ1
Inner ring(mm)-	10
Outer ring(mm)-	26
Width(mm)-	8
Weight(Kg)-	0.023
Materials-	Chrome steel/GCR15
Precision grade-	P4/P2
Lubrication type-	Grease lubrication
Contact Angle-	C=15°;AC=25°
Material(Ball)-	SN24:Ceramic ball(Si3N4)
Number of Row-	Single rows
Material(Cage)-	TYN-PA;TR-PF
Combination-	SU:Universal combination (single row) DU:Universal combination (double rows) DB: Back-to-back combination DF: Face-to-face combination DT: Parallel combination DBD.DFD.DTD: Three rows DBB.DFF.DBT.DFT.DTT: Four rows

B . 7000 HQ1 Ceramic Ball Bearings Specification Sheet
Model Number	Dimensions			α=15°		α=25°		Material (Cage )	Weight (kg) Approx
				Limiting speed		Limiting speed
	d	D	B	Basic load rating	Lubrication	Basic load rating	Lubrication
				Cr Cor	Grease Oil	Cr Cor	Grease Oil
7000 HQ1	10	26	8	3.4 1.5	89000 149000	3.3 1.4	79000 129000	PA/PF	0.023

Categories:	Angular Contact Ball Bearings Ceramic Ball Bearings
Related Search:	7000 HQ1 AC/C P4,7000C Ceramic Ball Bearings,7000C Spindle bearing,7000C High Speed Bearing,10x26x8mm Bearing

Product

Features

Angular Contact Ball bearing with Ceramic balls (Si3N4), used in high precision

Spindle and Motors

Series

Introduction

High Speed Ceramic Ball Type:ISO 10 Series - highest load, second lowest speed

bearings-70 Series Angular Contact Bearings

Series

Model No.

7000HQ1,7001HQ1,7002HQ1,7003HQ1,7004HQ1,7005HQ1,7006HQ1,7007HQ1,7008HQ1,7009HQ1,

7010HQ1,7011HQ1,7012HQ1,7013HQ1,7014HQ1,7015HQ1,7016HQ1,7017HQ1,7018HQ1
